XA-2
XA-2 är en kompakt och smidig HDMI "mönster generator" för att testa och felsöka HDMI enheter.
XA-2 kan ställas in med t.ex:
6 olika upplösningar,
4 olika test mönster,
HDCP ( 1.4, 2.2, utan HDCP )
m.m
?The XA-2 is an advanced yet compact and convenient pattern generator for testing and troubleshooting HDMI devices. There are 6 resolution settings covering 4K Ultra HD and Full HD resolutions, 4 test patterns, HDCP (1.4, 2.2 and non-HDCP), and 3 audio settings each providing a large array of test signals. With simple to use control via buttons on the front panel, and LED indicators for quick viewing of the current status, this pattern generator is a must have tool for any professional AV integrator.
Generates HDMI resolutions up to 6Gbps 4K2K@60Hz
Generates HDCP v1.4, HDCP v2.2 and non-HDCP signals
Resolutions supported : 720p@60, 1080p@60, & 4K@30/60
Supports external analog stereo and optical digital audio inputs
Video bandwidth support : 18Gbps
Features:
HDMI 2.0, HDCP 2.2 and DVI compliantGenerates HDMI resolutions up to 6Gbps 4K2K@60Hz
Generates HDCP v1.4, HDCP v2.2 and non-HDCP signals
Resolutions supported : 720p@60, 1080p@60, & 4K@30/60
Supports external analog stereo and optical digital audio inputs
Video bandwidth support : 18Gbps
Specifications:
Input: | 2x RCA [1x Analogue audio Stereo (L/R)] 1x Toslink [1x Optical 2 Channel LPCM] 1x USB Mini B [1x Service Port - Propriety Data] |
Output: | 1x HDMI [1x HDMI Uncompressed AV and Data] |
: | |
PSU: | 5V/2.6A |
Dimensions: | 87mm [W] x 78mm [D] x 30mm [H] |
Net. Weight: | 202g |
Gross Weight: | 500g |
