EDID Manager, 4K, HDCP 2.2, HDMI 2.0, 6G

Logga in för att se priser och lagerstatus.

RE-EDID-4K22

RE-EDID-4K22 är designad för att kunna manipulera och göra förändringar av EDID informationen som källor och skärmar skickar mellan varandra för att säkerställa att rätt video och ljud signaler används. Den nya 4K22 modellen har stöd för 4K upplösning samt HDCP 2.2 och HDMI 2.0 stöd. Målet är att göra det lättare att installera och konfigurera A/V installationer, hembio system och A/V test utrustning. Enheten har en sofistikerad inlärnings funktion vilket tillåter användaren att läsa ur och programmera in EDID signalen i systemet. Den har även stöd för EDID emulering och

"Bypass" läge.


Denna prylen är idealisk för att överkomma problem mellan video källor och skärmar som beror på EDID, speciellt mellan en dator och A/V system där EDID ibland

kan vara felaktig eller missvisande.



The RE-EDID-4K22 is designed to manage and manipulate the HDMI/DVI EDID information provided to a HDMI source device by a connected display. EDID contains critical information about the capabilities of the connected display, including audio and video format support, HDMI feature support, etc. This product aims to simplify the technical complications that often arise when performing video system integration, home cinema installation, integrating commercial displays or audio/video equipment testing. It also supports EDID Emulation and Bypass modes. This device is perfect to overcome source and screen compatibility issues, particularly when integrating PC's into an AV system.

Features


HDMI input and output with 18Gbps (6G) 4K UHD support
HDCP 1.4 and 2.2 compliant
Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) & 4096×2160@60Hz (4:4:4, 8-bit)
Supports 48-bit Deep Color up to 1080p@60Hz
Supports Four different EDID modes : Read / Write / Emulate / Bypass modes
Read Mode : Reads the TV/display’s EDID information
Write Mode : Overwrites the TV/display’s EDID information (TV/display needs to be able to support overwrite function)
8 unique sets of EDID settings may be stored via the learning procedure.
Emulator Mode : Allows the source device to read the selected EDID information from the unit’s default or learnt EDID memory
Bypass Mode : Allows the source device to read the EDID information from the TV/display directly
Supports DVI sources when used with a DVI to HDMI adaptor (not supplied)
Supports CEC functionality

Specification:


td>715g
Input:
1x HDMI [1x HDMI Uncompressed AV and Data]
1x USB Mini B [1x Service and PC port Propriety Data]
Output:
1x HDMI [1x HDMI Uncompressed AV and Data]
 :
 :
PSU:
5V/2.6A
Dimensions:
83mm [W] x 128mm [D] x 25mm [H]
Net. Weight:
260g
Gross Weight:
