HDBaseT mottagare, 4K, HDR, 5Play, AVLC

Logga in för att se priser och lagerstatus.

PUV-1810RX-AVLC

Mottagaren PUV-1810RX-AVLC gör det möjligt att ta emot video, upp till och med 4K UHD med 10/12-bitdjup och HDR, med hjälp av den nya AVLC (Adaptive Visually Lossless Compression) tekniken, tillsammans med HD-ljud, IR båda hållen, RS-232 och Power over HDBaseT upp till 100 meter.


The new PUV-1810RX-AVLC Receiver enables video resolutions up to 4K UHD including 10/12-bit HDR & Dolby Vision, to be received along with HD audio, 2-Way IR, RS-232, PoH (Power over HDBaseT) and LAN signals from a distance of 100m. This solution provides advanced signal management ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are received simultaneously over a single CAT6a/7 cable up to 70m.

Despite the 10.2Gbps limitation of HDBaseT™ technology, this groundbreaking product enables data rates of up to 18Gbps to be received using AVLC (Adaptive Visually Lossless Compression) Technology. The receiver enables 4KUHD sources up-to and including 4K@60Hz (4:4:4 8-bit) as well as 10/12 bit sources with HDR (Including Dolby Vision) to be received over distance from a compatible transmitter. The result is a perfect 6G 4K visually lossless image delivered to the display screen.

Features:


HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR & RS-232 pass through)
Supports up-to 4K UHD (18Gbps, 4K @50/60Hz 4:4:4 8-bit) video output
AVLC (Adaptive Visually Lossless Compression)
AVLC Features manual selection between High Quality and Standard compression from TX (Useful for longer cable runs)
Supports 10-bit and 12-bit HDR (High Dynamic Range)
Supports output resolutions up to 4K @50/60Hz (4:4:4 8-bit)
Supports Deep Colour input and output up to 12-bit
Supports CEC Bypass
4K 3G Timings and 1080p up-to 100 Metres, 4K 6G Timings upto 70 Metres
Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
Supports 3D signals

Specifications:


Input:1x RJ45 [1x HDBaseT HDMI & Propriety Data]
1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
Output:1x HDMI [1x HDMI Uncompressed AV and Data]
1x 9pin Dsub [1x RS-232 Data]
1x 3.5mm Stereo mini-jack [1x Infra Red Emitter]
1x RJ45 [1x LAN Serving]


Power Supplied by:PoH
Dimensions:116mm [W] x 128mm [D] x 16mm [H]
Net. Weight:357g
Gross Weight:572g
