SY-398H
Utgången, lämplig ersättare SY-295N
Liten och smidig komposit eller S-video till HDMI konverter med ljud.
This Video to HDMI™ converter can convert CV/SV (NTSC or PAL or SECAM) to HDMI resolutions of XGA to UXGA, or HD resolutions of 480p to 1080p. With a frame rate conversion feature that allows users to view DVD, VCR or video game sources on the HD monitor/TV, this device has an On-Screen Display function that allows users to easily select the output resolution and the audio input, after which both the video and audio signal are combined into an HDMI signal so they can be output to a compatible display.
Features
Operates in NTSC 3.58 and PAL & SECAM system
Can scale CV/SV to HDMI format
PC Output resolutions: XGA, SXGA, UXGA
Component Output resolutions : 480p/576p, [email protected] or 60,[email protected] or 60
3D (frame based) motion adaptive YNR/CNR noise reduction
On-Screen Display
Advance 3D motion adaptive de-interlace
Automatic 2:2 & 3:2 film mode detection
Play video games on your HD monitor/TV
High-resolution output picture
Plug & play- no drive software required
Component resolution support 50 to 60 frame rate convertion only. (not 60 to 50)
PC resolution frame rate only supports 60Hz output
Specification
Inputs:
1x RCA [1x Composite]
1x S-video plug [1x S-video]
1x Stereo mini-jack [1x Analogue Stereo(L/R)]
Outputs: 1x HDMI [1x HDMI Uncompressed AV and Data]
Power:5V/1A, DC (US/EU standards, CE/FCC/UL certified)
Dimensions:105mm (W) x 65m (D) x 25mm (H)
Gross Weight:280g
Net. Weight:200g
